Professional CAD Elevation Drawings (External & Internal)

Get Your CAD Elevations Sorted TODAY

Elevations Drawn Right — So the Build Looks Like the Design.

Existing and proposed elevations for extensions, refurbishments, frontage changes and signage. Millimetre-accurate from LiDAR scan or your plans. Delivered in DWG, DXF and PDF.

Get Your CAD Elevations Sorted Today

Guessing heights from photos? That’s how mistakes get built.

Inaccurate elevations lead to planning pushback, wrong cladding quantities, window orders that don’t fit, and builders improvising on site. Expensive, slow, and avoidable.

We capture, draft and annotate elevations your planner and builder both trust.

Consistent datums and levels, clear materials/finishes, ridge/eaves heights, roof pitches, opening sizes and head/sill heights — all tied back to your floor plans and sections.

What’s Included in Your Elevation Set

Crisp, consistent elevations that hold up to planning scrutiny and keep site teams aligned.

Existing & Proposed Elevations

Front, rear and side elevations at 1:100 or 1:50 with clear naming and orientation.

Datums, Levels & Pitches

Finished floor, eaves and ridge levels; roof pitches and key vertical dimensions.

Openings & Setouts

Window/door sizes with head & sill heights; lintels, cills, reveals and alignments.

Materials & Finishes

Brick/stone types, cladding, render, roof coverings, rainwater goods and notes.

Street Scene (Optional)

Context elevations or montage to support design and streetscape assessments.

LiDAR-Backed Accuracy

Millimetre-accurate capture for reliable setout and seamless coordination.

Delivered in DWG, DXF and PDF formats. Coordinated with your floor plans and sections; title blocks and revision control included.

Getting Precise Elevations Shouldn’t Be a Tall Order.

Elevation Drawings Delivered in 3 Simple Steps

Step 4

Capture

We LiDAR-scan your property (or work from reliable existing data), take site photos, confirm control levels, and gather any street context you need for planning.

Draft

Existing & Proposed elevations at 1:100 or 1:50, fully annotated: materials, finishes, opening sizes, head/sill heights, eaves/ridge levels, roof pitches, downpipes/vents. Optional street scene montage.

Step 3

Deliver

Clean, layered DWG/DXF and a polished PDF set with title blocks and revision control. Fast tweaks when the design evolves.

Warehouses, Offices, Storefronts — All Drawn, All 5-Star.

R
RVia Google
Review on behalf of my parents- Mr & Mrs Sparrow We were really struggling to get our Land Registry plans approved due to confusing and unhelpful advice from a solicitor. Then we spoke to Kev — and what a difference! With just one quick call, he clearly explained what needed to be done and suggested we submit both our own and our neighbour’s plans together. Thanks to his expert advice, everything was approved straight away. He completed the plans quickly, efficiently, and at a very reasonable price. No stress, no hassle — just a great service from start to finish. Absolutely brilliant. Highly recommend Kev to anyone needing Land Registry Compliant Plans.
Deni Nygate
Deni NygateVia Google
Kevin is flexible, listens to what has been asked. He is knowlegeable about ideas and suggestions and gives you leave options. The plans were clear to read and were done to a professional high standard. If you live in Essex and want a good value price then Kevin is the man to contact. My plans were submitted on Monday as the price is going out and they were done in a timely manner.
Charlotte Manson
Charlotte MansonVia Google
Kev from Surv Design was incredibly helpful when we needed land registry compliant plans drawn up for our leasehold property. After a couple of months when our buyers solicitor came back asking for revisions to be made, we received these within a couple of days. Thank you Kev for making a stressful process much easier! We are very grateful for your time and help!
Glen Carlos
Glen CarlosVia Google
Kev and the team have been amazing at working with me to ensure my planning application goes through smoothly. I live in a conservation area so it was daunting to even begin the process but Kev put me at ease straight away. Communication has been great and I would highly recommend Surv Design.
Pete Johnson
Pete JohnsonVia Google
My experience in dealing with Mr Kev Miller of Essex Architects and Party Wall Surveyors is one of thankfulness. Having discussed my problem with Kev, which he fully understood, I sent him some follow-up details which were used by him to give a quick response. I am extremely grateful for his time, knowledge and understanding in dealing with my problem.
Shouab Miah
Shouab MiahVia Google
I use them first time Mr kev Miller is the best man I ever seen and very reasonable price and very good service he handling our case smoothly he is very knowledgeable and friendly we got approved our side double extension and back 6 metre extension. Thank very much kev for your hard work.
Elizabeth Szkolny
Elizabeth SzkolnyVia Google
Excellent service from Kev and Millie at Surv Design. Would not hesitate to recommend them to anyone.
Roger Essex
Roger EssexVia Google
Straight forward talking and great communication from start to finish. Highly recommended for your project.
CAD Elevation Drawings

Production-Ready Elevations for Planning, Tender & Build

We support architecture, construction, engineering and manufacturing teams

Need clean, consistent CAD elevations that contractors, planners and clients can read at a glance? SurvDesign produces external and internal elevations with correct levels, materials, annotations and references—ready for applications, pricing, fabrication and site install.

What We Draw

  • External façades — full street elevations, rear/side elevations, gables, dormers

  • Internal elevations — kitchens, bathrooms, joinery runs, reception/retail walls

  • Shopfront & signage elevations — glazing modules, frames, signage zones, lighting pick-ups

  • Cladding & façade packages — panel set-outs, joints, fixings, flashing lines

  • Window/door coordination — head/sill/parapet lines, lintels, opening types, schedule call-outs

  • Context elevations — adjoining buildings for planning townscape views

  • As-built elevations — red-line updates for O&M handover

Inputs We Can Work From

    • Measured surveys (DWG, PDF) or point clouds (E57/RCP/RCS)

    • LiDAR scan by us if you don’t have measured data

    • Photos with dimensions (we’ll advise on limits)

    • Legacy PDFs/sketches for Scan-to-CAD conversion

    • BIM/architectural base files to align datums and gridlines

Output & Standards

      • DWG + PDF as standard; DXF/IFC on request

      • Sheet sizes and scales to brief (e.g., 1:50/1:100 ext., 1:20/1:10 joinery)

      • Clear datums/levels (FFL/SFL), grid references and orientation

      • Material tags & hatch conventions, render/brick/stone/metal annotations

      • Buildable note sets (flashings, weeps, sealants, cavity closers) where required

      • Consistent layer naming, blocks, title blocks; revision clouds & logs

Our Process

    • Brief & sources — scope, scales, standards, required sheets.

    • Base build — trace from survey/point cloud; align datums and grids.

    • Annotate & coordinate — materials, levels, openings; link to schedules.

    • Issue & iterate — draft PDFs with clouded revisions; integrate comments.

    • Final issue — clean DWGs + plotted PDFs, revision history included.

Coordination & Add-Ons

  • Sections/details: companion sections and key junction details on request

  • Schedules: windows/doors, finishes, signage, cladding panels

  • Photo-matching/orthos: orthographic façades from point-clouds/photos for complex geometry

  • Condition discharge: material sample/elevation packs to satisfy planning conditions

Why Choose SurvDesign

    • Technician-led clarity — crisp linework, legible annotation, reliable datums

    • Fast turnaround & fixed pricing — dependable for live programmes

    • Survey to sheet — we can LiDAR scan, model orthos and deliver buildable sheets end-to-end
